IK ELECTRIC IEC 63 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 0.25hp, 60 Hz, 220V/380V, 3600 RPM, TEFC
  • IK ELECTRIC IEC 63 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 0.25hp, 60 Hz, 220V/380V, 3600 RPM, TEFC
IK ELECTRIC IEC 63 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 0.25hp, 60 Hz, 220V/380V, 3600 RPM, TEFC

IK ELECTRIC IEC 63 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 0.25hp, 60 Hz, 220V/380V, 3600 RPM, TEFC

Brand: IK Electric
SKU: B35IE102kW014HP2P
Availability: In stock
Request for Quote

Part : IK 3-phase TEFC(Totally Enclosed, Fan-Cooled) General Purpose Motor

Type: B35 Horizontal Vertical type

Model Number: IE1, 3Φ  0.2Kw (0.25HP)

RPM : 3,600

Pole : 2

Voltage : 220V/380V

Hertz : 50 / 60 Hz

IP rating : 55

Manufacturer : IK ELECTRIC

UL Certificate Number : UL-US-247393-0 (US), UL-CA-2421468-0 (Canada) / UL Report Reference : E530774-20240715

Product Description

IEC 63 frame single-phase IEC metric general purpose AC motors have a 11mm diameter, 30mm length shaft whose center is 63mm above the base mounting surface. IEC63 motors are commonly used outside U.S. countries to power compressors, conveyors, fans, and pumps that require International Electrotechnical Commission (IEC) electrical standards.

B35 Horizontal Vertical Type IK Hydraulic Unit Motor?

? Condenser Running

? 3-Phase TEFC Standard Motor

Rigid and Durtors

? Condenser Running
? Condenser Starting & Running

?

POWER
3-Phase, AC(220V / 380V), 50 / 60Hz

Product Specifications

Dimensional drawing

IK

Frame Output Dimension(mm) Bearings
Size (kW) Overall DE Shaft extension Base
63M 2P S(Hole) PCD M N H C HA LA L X T D E F FA G A B AB BA K1 K2 DE ODE
0.2 10 100 95 140 63 40 145 152 206 124 3 11 23 4 20 2.5 100 80 118 100 7 10 6202ZZ 6202ZZ

Brand IK Electric
Availability In Stock
Estimated Delivery 28 Days
