IK ELECTRIC IEC 71 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 0.5hp, 60 Hz, 220V/380V, 3600 RPM, TEFC
  • IK ELECTRIC IEC 71 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 0.5hp, 60 Hz, 220V/380V, 3600 RPM, TEFC
IK ELECTRIC IEC 71 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 0.5hp, 60 Hz, 220V/380V, 3600 RPM, TEFC

IK ELECTRIC IEC 71 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 0.5hp, 60 Hz, 220V/380V, 3600 RPM, TEFC

Brand: IK Electric
SKU: B35IE104kW012HP2P
Availability: In stock
Request for Quote

Part : IK 3-phase TEFC(Totally Enclosed, Fan-Cooled) General Purpose Motor

Type: B35 Horizontal Vertical type

Model Number: IE1, 3Φ  0.4Kw (0.5HP)

RPM : 3,600

Pole : 2

Voltage : 220V/380V

Hertz : 50 / 60 Hz

IP rating : 55

Manufacturer : IK ELECTRIC

UL Certificate Number : UL-US-247393-0 (US), UL-CA-2421468-0 (Canada) / UL Report Reference : E530774-20240715

Product Description

IEC 71 frame single-phase IEC metric general purpose AC motors have a 14mm diameter, 30mm length shaft whose center is 71mm above the base mounting surface. IEC71 motors are commonly used outside U.S. countries to power compressors, conveyors, fans, and pumps that require International Electrotechnical Commission (IEC) electrical standards.

B35 Horizontal Vertical Type IK Hydraulic Unit Motor?

? Condenser Running

? 3-Phase TEFC Standard Motor

Rigid and Durtors

? Condenser Running
? Condenser Starting & Running

?

POWER
3-Phase, AC(220V / 380V), 50 / 60Hz

Product Specifications

Dimensional drawing

IK

Frame Output Dimension(mm) Bearings
Size (kW) Overall DE Shaft extension Base
71M 2P S(Hole) PCD M N H C HA LA L X T D E F FA G A B AB BA K1 K2 DE ODE
0.4 10 130 110 160 71 45 169 178 237 142 3 14 30 5 25 3 112 90 130 105 7 10 6203ZZ 6202ZZ
