IK ELECTRIC IEC 100 Frame Aluminum Metric Motor, B35 Horizontal Vertical , Single-Phase, 3hp, 60 Hz, 220V, 1800 RPM, TEFC
  • IK ELECTRIC IEC 100 Frame Aluminum Metric Motor, B35 Horizontal Vertical , Single-Phase, 3hp, 60 Hz, 220V, 1800 RPM, TEFC
IK ELECTRIC IEC 100 Frame Aluminum Metric Motor, B35 Horizontal Vertical , Single-Phase, 3hp, 60 Hz, 220V, 1800 RPM, TEFC

IK ELECTRIC IEC 100 Frame Aluminum Metric Motor, B35 Horizontal Vertical , Single-Phase, 3hp, 60 Hz, 220V, 1800 RPM, TEFC

Brand: IK Electric
SKU: B35IE122kW3HP4
Availability: In stock
Request for Quote

Part : IK Single-phase TEFC(Totally Enclosed, Fan-Cooled) General Purpose Motor

Type: B35 Horizontal Vertical type

Model Number: IE1, 1Φ  2.2Kw (3HP)

RPM : 1,800

Pole : 4

Voltage : 220V

Hertz : 60 Hz

IP rating : 55

Manufacturer : IK ELECTRIC

UL Certificate Number : UL-US-247393-0 (US), UL-CA-2421468-0 (Canada) / UL Report Reference : E530774-20240715

Product Description

IEC 100 frame single-phase IEC metric general purpose AC motors have a 28mm diameter, 60mm length shaft whose center is 100mm above the base mounting surface. IEC100 motors are commonly used outside U.S. countries to power compressors, conveyors, fans, and pumps that require International Electrotechnical Commission (IEC) electrical standards

B35 Horizontal Vertical Type IK Hydraulic Unit Motor?

? Condenser Running

? Single-Phase TEFC Standard Motor

Rigid and Durtors

? Condenser Running
? Condenser Starting & Running

?

POWER
Single-Phase, AC(220V), 60Hz

Product Specifications

Dimensional drawing

IK

Frame Output Dimension(mm) Bearings
Size (kW) Overall DE Shaft extension Base
100L 4P S(Hole) PCD M N H C HA LA L X T D E F FA G A B AB BA K1 K2 DE ODE
2.2 12 215 180 250 100 63 231 256 360 196 4 28 60 8 45 34 160 140 190 165 12 15 6206ZZ 6205ZZ

Brand IK Electric
Availability In Stock
Estimated Delivery 28 Days
