IK ELECTRIC IEC 80 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 1hp, 60 Hz, 220V/380V, 3600 RPM, TEFC
  • IK ELECTRIC IEC 80 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 1hp, 60 Hz, 220V/380V, 3600 RPM, TEFC
IK ELECTRIC IEC 80 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 1hp, 60 Hz, 220V/380V, 3600 RPM, TEFC

IK ELECTRIC IEC 80 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 1hp, 60 Hz, 220V/380V, 3600 RPM, TEFC

Brand: IK Electric
SKU: B35IE3075kW01HP2P
Availability: In Stock (ships from Chicago in 1-2 business days)
$800.00
IK ELECTRIC IEC 80 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 1hp, 60 Hz, 220V/380V, 3600 RPM, TEFC
IK ELECTRIC IEC 80 Frame Aluminum Metric Motor, B35 Horizontal Vertical , 3-Phase, 1hp, 60 Hz, 220V/380V, 3600 RPM, TEFC
$800.00

Product Description

IEC 80 frame single-phase IEC metric general purpose AC motors have a 19mm diameter, 40mm length shaft whose center is 80mm above the base mounting surface. IEC80 motors are commonly used outside U.S. countries to power compressors, conveyors, fans, and pumps that require International Electrotechnical Commission (IEC) electrical standards.

B35 Horizontal Vertical Type IK Hydraulic Unit Motor

• Condenser Running

• 3-Phase TEFC Standard Motor

Rigid and Durable Motors

• Condenser Running
• Condenser Starting & Running



POWER
3-Phase, AC(220V/380V), 60Hz

Product Specifications

Dimensional drawing

IK

Frame Output Dimension(mm) Bearings
Size (kW) Overall DE Shaft extension Base
80M 2P S(Hole) PCD M N H C HA LA L X T D E F FA G A B AB BA K1 K2 DE ODE
0.75 12 165 130 200 80 50 189 209 266 160 3.5 19 40 6 30 3.5 125 100 149 130 10 15 6204ZZ 6203ZZ

Brand IK Electric
Availability In Stock
Estimated Delivery 28 Days
