NSK Angular Contact Bearing 80BAR10STYNDBLP4A
Brand: IndustryNest
SKU:
591080BA1001NS
Availability:
In Stock (ships from Chicago in 1-2 business days)
$863.56
NSK Angular Contact Bearing 80BAR10STYNDBLP4A
$863.56
Product Description
The angular contact ball bearing falls in a wide range of structures.
The single-row bearing can carry both the radial load and the unidirectional axial load and with DB and DF combinations compassing the four-point ball contact.
The double-row bearing can carry both the radial load and the bi-directional axial load.
The angular contact ball bearing is applicable to high-speed and high-precision rotations.
Such bearings are mainly applied to the main shaft of machine tools, high-frequency motors, oil pumps, air compressors and printers
The four-point contact ball bearings are mostly applied to the roller drum of rolling mills for the sake of carrying the radial load.
Product Specifications
| Specifications for NSK Angular Contact Bearing 80BAR10STYNDBLP4A | ||
| Bearing Numbers | 80BAR10E | |
| Boundary Dimensions | d | 80 mm |
| D | 124mm | |
| B | 40.5 mm | |
| r (min.) | 1.1 mm | |
| r1 (min.) | 0.6 mm | |
| Recommended Grease Quantities | 3.8 cc/Bearing | |
| Contact Angle | 30 ° | |
| Limiting Speed | Grease Oil | 7900 |
| 10000 | ||
| Mass (approx.) | 0.83 kg | |
