Aryung ARD-440 piston distributor
  • Aryung ARD-440 piston distributor
  • Aryung ARD-440 dimension drawing
Aryung Piston Distributor ARD-443 (3 Outlets)

Aryung Piston Distributor ARD-443 (3 Outlets)

Brand: Aryung
SKU: ARD443
Availability: Backorder (estimated delivery: 30 Days)
Product type: Piston Distributor
Request for Quote

The Aryung ARD-443 is a 3-outlet piston (positive-displacement) distributor for quantitative oil lubrication systems. Each outlet takes a valve code that sets its discharge per cycle.

Built to order: made by Aryung in Korea and ships in about 30 days. Request a quote for price and lead time, or call 847-466-5459.

Specifications

Outlets 3
Working pressure 0.8 to 3.0 MPa
Central pipe thread M10 x 1.0
Branch pipe thread M8 x 1.0
Dimensions N / W / L (mm) 17 / 56 / 68
Valve codes 1 = 0.03, 2 = 0.06, 3 = 0.10, 4 = 0.16 cc per cycle

Ordering

Order with a valve code for each outlet, for example ARD-445-22311 (outlets 1 to 5 set to codes 2, 2, 3, 1, 1).

ARD-443 drawing

Downloads

Specifications from Aryung's catalog. Confirm details with us before ordering.
