Parts : Angular Contact Ball Bearing

Part Number : 7913CTYNSULP4 (5917913CP401NS)

Dimensions : 65 mm x 90 mm x 13 mm

Manufacturer : NSK

Delivery & Return

Product Description

The NSK range of angular contact ball bearings has been designed to meet the increasingly demanding requirements of original equipment manufacturers.

These bearings have a contact angle so that they can sustain significant axial loads in one direction together with radial loads.

Furthermore, since an axial component is generated when a radial load is applied,

these bearings are generally used in pairs, triple sets, quadruple sets, or multiple sets. NSK offers one of the most comprehensive ranges of angular contact ball bearings.

Product Specifications

NSK Angular Contact Ball Bearing 7212CTYNSULP4

Boundary Dimensions
d65 mm
D90 mm
B13 mm
C13 mm
a16.9 mm
r min1 mm
r1 min0.6 mm
da min71 mm
Da max84 mm
ra max1 mm
Weight0.208 kg
