Parts : Angular Contact Ball Bearings
Part Number : 7207CTYNSULP4 (5917207CP401NS)
Dimensions : 35 mm x 72 mm x 17 mm
Manufacturer : NSK
Categories:
Product Description
The NSK range of angular contact ball bearings has been designed to meet the increasingly demanding requirements of original equipment manufacturers.
These bearings have a contact angle so that they can sustain significant axial loads in one direction together with radial loads.
Furthermore, since an axial component is generated when a radial load is applied,
these bearings are generally used in pairs, triple sets, quadruple sets, or multiple sets. NSK offers one of the most comprehensive ranges of angular contact ball bearings.
Product Specifications
| Bearing Dimensions | |
| d | 35 mm |
| D | 72 mm |
| B | 17 mm |
| C | 17 mm |
| a | 15.7 mm |
| r min | 1.1 mm |
| r1 min | 0.6 mm |
| da min | 42 mm |
| Da max | 65 mm |
| ra max | 1 mm |
| Weight | 0.32 kg |
| Product Name | NSK Angular Contact Ball Bearings 7207CTYNSULP4 |
|---|---|
| Shipping For Product | 0.000000 |
| Calculate Shipping | Per Product Quantity |
| Enable Shipping Per Product | No |
| Brand | ASM enterprise |
| Enable Request a Quote | No |
